Body Material:PPS

Cable connection:Digital

Cable length:10 m

Compliance:Hazardous location, Maritime, CE

Electrode type:Specialty - GoldFlow:3 m (10 ft.) per second, maximum

Housing material:PPS

Material (electrode):Gold

Measuring range:-1500 to +1500 mV ORP

Mounting:Convertible

Operating temperature range:–5 to 70 °C (23 to 158 °F) pHD and ORP

Before initial pH calibration, calibrate the temperature measurement when the sensor is in water or buffer which is at approximately the same temperature as the pH buffers.

Sensitivity:± 0.5 mV

Sensor cable:Integral 4 conductor cable with one shield and polyurethane jacket; rated to 105 °C (221 °F); 10 m (33 ft.) standard length

Sensor type :Digital

Temperature accuracy:± 0.5 °C (± 0.9 °F)

Temperature sensor:Sensor

Pressure/Temperature Limits Digital: 6.9 bar

Transmission distance:1000 m (3280 ft.), maximum when used with a termination box 100 m (328 ft.), maximum

Warranty:24 months

Wetted materials:PEEK or PPS, salt bridge of matching material with PVDF junction, glass process electrode, titanium ground electrode, and FKM/FPM O-ring seals (pH sensor with optional HF-resistant glass process electrode has 316 stainless steel ground electrode, and perfluoroelastomer wetted O-rings; consult factory for other available wetted O-ring materials)
